2"STM Deep well pump

Keywords:

2”STM series

Category:

2”STM series

Description:

For water supply from wells or reservoirs

E-mail:

Tel:

WhatsApp:

Product Description
Operation Conditions
Performance

Applications
For water supply from wells or reservoirs
For domestic use, for civil and industrial applications
For garden use and irrigation

Motor and Pump
Rewindable motor
Single-phase:220-240V/50Hz
Equip with start control box or digital auto-control box
Pumps are designed by casing stressed
Curve tolerance according to ISO 9906

Options on request
Special mechanical seal
Other voltages or frequency 60Hz
Single phase motor with built-in capacitor

The 2"STM Deep Well Pump is designed for efficient water extraction in narrow wells, offering high lift, stable performance, and long service life. Built with corrosion-resistant materials and a powerful motor, it ensures reliable water supply for households, farms, and irrigation systems. The compact 2-inch design allows installation in tight boreholes, solving problems of limited space and low water output. An ideal solution for users seeking dependable deep-well pumping efficiency.
Maximum fluid temperature up to +35℃
Maximum sand content:0.25%
2ST minimum well diameter:2"

Performance chartn≈2850rpm

PERFORMANCE DATA 50Hz

MODEL	POWER		Capacity and Head
1~ 220-240V	kW	HP	m³/h	0	0.12	0.24	0.36	0.48	0.60	0.72	0.84	0.96
1~ 220-240V	kW	HP	l/ min	0	2	4	6	8	10	12	14	16
2STM0.7/26	0.18	0.25	H(m)	35	32	30	28	26	23	20	16	12
2STM0.7/32	0.25	0.33		43	40	37	35	32	29	24	2	15
2STM0.7/38	0.37	0.50		51	47	44	41	38	34	29	24	18

DIMENSIONS AND WEIGHTS

MODEL	DN	DIMENSIONS(mm)					WEIGHT(kg)
1~ 220-240V	DN	P	M	T	φD	L	P	M	T
2STM0.7/26	½"/¾"	778	499	1277	φ50	55	2.0	4.3	6.3
2STM0.7/32	½"/¾"	942	499	1441	φ50	55	2.3	4.3	6.6
2STM0.7/38	½"/¾"	1084	499	1583	φ50	55	2.6	4.3	6.9
