6SR30
Keywords:
6SR series
Category:
Description:
- Product Description
- Operation Conditions
- Performance
-
Applications
For water supply from wells or reservoir
For domestic use, for civil and industrial application
For garden use and rrigationMotor and Pump
Rewindable motor or Full obturated screen motor
Three-phase:380V-415V/50Hz
Direct start(1 cable)
Star-delta start(2 cable)
Equip with start contol box or digital
auto-control box
NEMA dimension standards
Curve tolerance according to ISO 2548Options on request
Special mechanical seal
Other coltages or frequency 60Hz
Warranty:1 year
(according to our general sales conditions).
-
Maximum fluid temperature up to +35°C
Maximum sand content:0.25%
Maximum immersion: 100m.
Minimum well diameter:6" -
PERFORMANCE DATA 50Hz
MODEL P2 DELIVERY n≈2850 l/min 1~
220V/240V3~
380V/415VkW HP m3/h 0 5 10 15 20 25 30 35 40 L/min 0 83 167 250 333 417 500 583 667 6SRM30-2 6SR30-2 3 4 Head(m)
29 27 25 23 21 17 14 9 4 6SRM30-3 6SR30-3 4 5.5 43 41 38 35 31 26 20 14 5 6SRM30-4 6SR30-4 5.5 7.5 57 54 50 47 42 35 27 18 7 — 6SR30-5 5.5 7.5 71 68 63 58 52 44 34 23 9 — 6SR30-6 7.5 10 86 81 76 70 62 52 41 27 11 — 6SR30-7 7.5 10 100 95 88 81 73 61 47 32 13 — 6SR30-8 9.2 12.5 114 108 101 93 83 70 54 36 15 — 6SR30-9 9.2 12.5 129 122 113 105 94 79 61 41 16 — 6SR30-10 11 15 143 135 126 116 104 87 68 45 18 — 6SR30-11 11 15 157 149 139 128 114 96 75 50 20 — 6SR30-12 13 17.5 172 162 151 140 125 105 81 54 22 — 6SR30-14 15 20 200 189 176 163 146 122 95 63 25 — 6SR30-16 18.5 25 229 216 201 186 167 140 108 72 29 — 6SR30-18 18.5 25 257 243 227 209 187 157 122 81 33 — 6SR30-21 22 30 300 286 264 244 219 184 142 95 38 — 6SR30-23 26 35 329 311 290 267 239 201 156 104 42 — 6SR30-25 30 40 357 338 315 291 260 219 169 113 45 — 6SR30-27 30 40 386 365 340 314 281 236 183 122 49
